Air Couplers - With Bulkhead Thread - Self Locking

Codice prodotto: iqsksX000000
Descrizione breve
  • Air Couplers for example for the expansion modular Machines
  • The Couplers are nly to Use with Air
  • They are NOT TO USE with Water or any other Fluids or Gases as Air


Descrizione dettagliata

Application
  • Air Couplers for example for the expansion modular Machines
  • The Couplers are nly to Use with Air
  • They are NOT TO USE with Water or any other Fluids or Gases as Air
Product Description
  • Functional Principle: Installed Lock, Blocks the Airflow by disconneting the hose. Connecting a
  • Hose gives the Airflow free.
  • Vantages: Cheaper than Coupling - Locks like a Coupling
Technical Data
  • Body: Galvanized Brass
  • Thread: Brass
  • O-Ring, Valve and Lip Sealing: NBR
  • Holding Claw, Valve Spring: Stainless Steel
  • Cartridge, Backup Ring: ZnDC
  • Loosening Ring, Valve, Valve Holder: POM

Variante

Hose-Ø
Thread

Annulla tutti filtri

Hose-Ø Thread Prezzoincl. IVACodice prodotto
x  4  M 12 x 1 € 5,20 € 6,19 IQSKS4000000
x  6  M 14 x 1 € 5,85 € 6,96 IQSKS6000000
x  8  M 16 x 1 € 6,70 € 7,97 IQSKS8000000
x  10  M 20 x 1 € 8,15 € 9,70 IQSKS1000000
x  12  M 22 x 1 € 11,25 € 13,39 IQSKS1200000
